JHKC-1 SF6 gas fast filling device
recommendation index：
SF6 automatic fast inflation
Automatic flip loading and unloading cylinder lift
Constant voltage constant temperature constant cur
PLC automatic intelligent control
SF6 Automatic Fast Filling Device Based on Multi-source Parameter Collaborative Control
Using battery power, wireless remote control device to walk, can climb slopes of 15-30 degrees, suitable for various harsh working conditions on site
Mainly used in high-voltage electrical equipment in substations of 330 kV and above, and can also be used for charging requirements of high-voltage electrical equipment below 330 kV
Inflatable flow rate | 0-250slpm |
Flow control accuracy | ±0.5% |
Flow control range | 0.01-100% full scale |
operating temperature | -10-60°C |
Mass flow meter inlet pressure | 1 MPa |
Mass flow meter outlet pressure | 0.8MPa - vacuum |
mode of communication | Modbus RTU RS485 |
SF6 gas filling speed | 250kg/h |
